Ultra-Bright P4mm Full HD Logo LED for Retail Promotion, 5000nits Luminance, 3840Hz Frequency
Logo LED Display is more innovative and unique than the traditional display screen. It breaks the limitations of the traditional rectangular display and provides more possibilities for information presentation. Whether in advertising, art installations or entertainment activities,Logo LED Display can attract people's attention and create a unique visual experience.
Parameters of Logo LED Display
| Item No. | Item | Product parameters |
| 1 | Pixel dots | 1 red 1 green 1 blue LED (SMD1820) |
| 2 | Pixel spacing | 4mm |
| 3 | Mold size | 300mm * 300mm (finished product diameter 600mm) |
| 4 | Modal resolution | 300mm * 300mm (finished product diameter 600mm) |
| 5 | LED chips | San'an |
| 6 | LED packaging forms | Nationstar |
| 7 | Indicating density | 62500 dots/m2 |
| 8 | Maximum White Balance Brightness | ≥5000cd/㎡ |
| 9 | Grayscale Classification | 16bits |
| 10 | Color Indication | ≥16.7M species,with a maximum of 2.81 million species |
| 11 | Out of control dots | ≤One thousandth |
| 12 | The Best Viewing Distance | ≥4M |
| 13 | Visual angles | Horizontal:≥120°Vertical:≥120° |
| 14 | Device Movement | 1/8 Scan |
| 15 | Brightness Adjustment | 256 level software adjustment,with 16 level automatic adjustment |
| 16 | Exchange frame rate | ≥60HZ |
| 17 | Refresh rate | 3840HZ |
| 18 | Control Methods | Nova TCC70 Asynchronous System |
| 19 | Protection level | IP65 |
| 20 | Screen lifespan | ≥100,000 hours |
| 21 | Working hours | ＞72 hours |
| 22 | Mean Time Between Failures | ＞1,000 hours |
| 23 | Work electric jade | AC220V±15%,50Hz±2 Hz |
| 24 | Environmental temperature and humidity | Temperature:-20℃～+60℃ Humidity:10%-95% |
| 25 | Power Consumption (maximum/average) | About 400W per Unit |
| 26 | Flatness | Image Interval≤0.5mm；Mold splicing gap≤0.5mm |
| 27 | Maintenance Method | Front |
| 28 | Screen weight | ≤17Kg/Unit |
| 29 | External | Round |
| 30 | Switching Mode Power Supply | 5V/40A |
| 31 | Publishing Method | WiFi |
Features of Logo LED Display
1. Hd clear full color display
HD display bring you with the real degree of visual experience, excellent picture layer and sharp color to give you a real degree of visual enjoyment!
2. Exclusive system with Mobile WIFI control
Exclusive system, five languages, support Apple Android system, comes with a dozen kinds of material templates, mobile APP one click upload pictures and videos, simple and convenient
3.The selection of high quality light
Select high light beads, the color of the beads is the same, the luminous Angle is large, the lamp beads have a life of 100,000 hours, energy saving and can play the lamp beads 24 hours a day without heating, so the highlight display
4. Use Outdoor LED module, waterproof and sun block,anti-glare
Application of Logo LED Display
1. Commercial advertisements
In shopping malls, shopping centers and other places, the Logo LED can effectively attract customers' attention and improve the communication effect of advertising because of its 360-degree viewing Angle and high visual appeal.
2. Exhibition display
In museums, exhibition halls and other places, the Logo LED can be used as an interactive display device to enhance the audience's visiting experience and make the display content more vivid and interesting.
3. Transportation hub
In public transportation hubs such as railway stations and airports, the Logo LED can be used to publish real-time information, flight dynamics and advertising, improve the efficiency of information transmission, and increase passengers' attention to advertising.
